Manhattan PoE+ Injector - Gigabit (IEEE 802.3at/af, output 48V DC/830 mA 10/100/1000)

Name: Manhattan PoE+ Injector - Gigabit (IEEE 802.3at/af, output 48V DC/830 mA 10/100/1000)
Brand: Manhattan
SKU: CEDRHALPOWMHINT560566
Price: 22389 HUF
Availability: InStock

22 389 Ft

Gyártó:

Manhattan

Garancia:

36 hónap

Külső Raktárból:

Szállítás 3-5 munkanap

Nem vásárolható!

A vásárlás után járó pontok: 784 Ft

Manhattan PoE+ Injector - Gigabit (IEEE 802.3at/af, output 48V DC/830 mA 10/100/1000)

Részletek

Standards

IEEE 802.3af (Power over Ethernet)

IEEE 802.3at (High-Power PoE+ Power over Ethernet)

IEEE 802.3 (10Base-T Ethernet)

IEEE 802.3ab (Gigabit Ethernet)

IEEE 802.3u (100Base-TX Fast Ethernet)

General

Media support:
- 100Base-TX Cat5 UTP/STP RJ45, 8 pin
- 1000Base-T Cat5e UTP/STP RJ45, 8 pin

Ports:
- 1 RJ45 1000 Mbps input port
- 1 RJ45 1000 Mbps data and power output port
- 1 power input connector for external power adapter

Protection functions:
- Short circuit protection for short GND
- Overload protection for currents over 1.8 A
- High-voltage protection for output voltage exceeding 58 V

Compatibility - general: all IEEE 802.3at- and IEEE 802.3af-compliant PoE devices

Supported INTELLINET NETWORK SOLUTIONS products:
- Wireless 300N Access Points (524735, 524711, 525251)
- IEEE 802.3at PoE+ Splitter (560443)
- Network Cameras (550932 NBCC30-IR, 550963 NFC30-IR, 550949 NFC30, 550987 NFD30, 551021 NFC31, 551045 NFC31-IR, 551229 NFD130-IR, 551236 NFD130-IRV)

Certifications: FCC Class B Part 15, CE 89/336/EEC

RJ45 Output Connector Pinout (Data + Power)

Pin 1: Rx+ (data receive) and feeding power [+]

Pin 2: Rx- (data receive) and feeding power [+]

Pin 3: Tx+ (data transmit) and feeding power [-]

Pin 4: NC (not connected)

Pin 5: NC (not connected)

Pin 6: Tx- (data transmit) and feeding power [-]

Pin 7: NC (not connected)

Pin 8: NC (not connected)

LED

PoE, Power

Power

Input: 100 – 240 V AC, 50 – 60 Hz

Power consumption: 42 watts (maximum)

Environmental
